Preamplificator doză pick-up MM/MC – Parasound Zphono XRM

3.699,00 lei

Parasound Zphono XRM este un preamplificator excelent, echilibrat atât din punct de vedere al sunetului cât şi al electronicii sale. Cu o bună separare a canalelor, zgomot foarte redus şi distorsiuni foarte mici discurile vinyl ascultate prin acest phono stage se aud complet, cu multe detalii.
Technical Specifications:
Frequency Response – 20-20 kHz, +/- 0.2 dB
Total Harmonic Distortion – 0.02% at 1 kHz
Signal to Noise Ratio, MM 40 dB Setting
> 94 dB, input shorted, IHF A-weighted
> 90 dB, input shorted, unweighted
Signal to Noise Ratio, MM 50 dB Setting
> 94 dB, input shorted, IHF A-weighted
> 90 dB, input shorted, unweighted
Signal to Noise Ratio, MC 50 dB Setting
> 92 dB, input shorted, IHF A-weighted
> 88 dB, input shorted, unweighted
Signal to Noise Ratio, MC 60 dB Setting
> 82 dB, input shorted, IHF A-weighted
> 80 dB, input shorted, unweighted
Inter-channel Crosstalk – > 80 dB at 1 kHz
Input Impedance – MM: 47k Ω / MC: 50-1050 Ω
Output Impedance – Unbalanced: 150 Ω / Balanced: 150 Ω per leg
Input Sensitivity at 1 kHz, 4mV Input
40 dB: 5 mV for 500mV output
50 dB: 5 mV for 1.5 Volts output
60 dB: 5 mV for 3 Volts output
Input Sensitivity at 1 kHz, 1V Output
40 dB: 10 mV for 1.0 Volt output
50 dB: 3.5 mV for 1.0 Volt output
60 dB: 1.8 mV for 1.0 Volt output
Total Gain
40 dB / 50 dB / 60 dB (unbalanced output)
46 dB / 56 dB / 66 dB (balanced output)
Rumble Filter
40 Hz high pass, 18 dB /oct.
Dimensions
Width: 8.5″ (220 mm)
Depth: 10″ (254 mm)
Depth: 12″ (305 mm) – cables connected
Height, with feet: 2″ (51 mm)
Height, without feet: 1.75″ (45 mm), 1U Weight
Net: 3.9 lbs. (1.8kg)
Shipping: 6.8 lbs. (3.1 kg)
Zphono XRM Owner’s Guide .PDF

Produs în stoc
